Depth of Field (DOF)

In optics, particularly as it relates to film and photography, the depth of field (DOF) is the portion of a scene that appears sharp in the image.

Although a lens can precisely focus at only one distance, the decrease in sharpness is gradual on either side of the focused distance, so that within the DOF, the unsharpness is imperceptible under normal viewing conditions.

For some images, such as landscapes, a large DOF may be appropriate, while for others, such as portraits, a small DOF may be more effective.

The DOF is determined by the subject distance (that is, the distance to the plane that is perfectly in focus), the lens focal length, and the lens f-number (relative aperture). Except at close-up distances, DOF is approximately determined by the subject magnification and the lens f-number.

For a given f-number, increasing the magnification, either by moving closer to the subject or using a lens of greater focal length, decreases the DOF; decreasing magnification increases DOF. For a given subject magnification, increasing the f-number (decreasing the aperture diameter) increases the DOF; decreasing f-number decreases DOF.

When focus is set to the hyperfocal distance, the DOF extends from half the hyperfocal distance to infinity, and is the largest DOF possible for a given f-number.

The advent of digital technology in photography has provided additional means of controlling the extent of image sharpness; some methods allow DOF that would be impossible with traditional techniques, and some allow the DOF to be determined after the image is made.

Effect of aperture on blur and DOF. The points in focus (2) project points onto the image plane (5), but points at different distances (1 and 3) project blurred images, or circles of confusion. Decreasing the aperture size (4) reduces the size of the blur circles for points not in the focused plane, so that the blurring is imperceptible, and all points are within the DOF.
